A165, A166, A167 and A168: Hand built hard wall multi purpose suction and discharge hose.
Sizes: 50mm to 915mm inside diameter
Lengths: Up to and including 300mm - 19.5 mtrs; 356mm and above - 12 mtr.
Applications: Fuel, oils, diesel, sea water, drill water, water, mud pump, chemicals, dry powders, cement, sand and gravel.
Lining: Smooth bore, mandrel built. See table below for options.
|Natural||NR||Water, medium abrasives|
|Nitrile||NBR||Fuels and oils|
|Neoprene||CR||Seawaterr, oil based mud|
|XLPE||XLPE||Chemicals, including solvents|
|Water Research Council
Reinforcement: Multiple layers of synthetic cord spiralled at a specific angle plus a single steel wire helix to give pressure and vacuum resistance. Hoses have a bend radius when pressurised to 6x the bore size and a minimum 3.5:1 safety factor.
Pressure: Hose assemblies are tested on request.
Cover: Abrasion and weather resistant Neoprene rubber issupplied as standard.
Couplings: Hoses are generally supplied assembled with built in vulcanised carbon steel nipples with slip-on welded or welding neck flanges to customers requirements. Alternatively swaged full bore fittings are available. Nipples can also be screwed if required. Wired in, wire free cuffs and beaded endsare all available.
Stainless steel, gun metal or aluminium fittings are also available. Steel fittings can be galvanised, plated or painted if required.
Sewage hose in a treatment plant, fitted with swaged in ends. The hose is additionally fitted with a swivel joint to eliminate torque.
Our Multipurpose Suction and Discharge Hoses are also available in a Fire Resistant configuration.
Special high strength synthetic textile cord fabric layers along with an 'eGlass' cover are used.
The hose carcase is protected by a thick layer of material made from a specially formulated flame resistant Neoprene rubber, giving excellent resistance to oils, sunlight, weathering and abrasion.
Finally, a non-toxic eGlass woven fabric layer is firmly bonded to the outside of the Neoprene rubber cover giving fire and heat resistance, allowing normal operation at temperatures of up to 6000C.
Please remember that our hoses can be designed to your requirements, if you do not see what you want, please call us.
