MannTek Drybreak Tank Unit

'MannTek' drybreak couplings have a large range of applications such as tanker loading, oil and chemical loading, food,pharmaceutical feedstock, or indeed, for any hazardous or critical fluid transfer application. 'MannTek' drybreak couplings provide a proven solution when a dry break is required.



'MannTek' Drybreak Hose Units providethe following options:-

  • 1' to 6' line size
  • 56mm, 70mm, 105mm, 119mm, 164mm and 238mm front flanges conforming to TEAM standards,ensuring compatibility with other couplings to the same standard.
  • Aluminium, Brass, Stainless Steel, Titanium, Hastelloy, PEEK bodies available.
  • Viton seals as standard with other seals as options
  • Optional Selectivity, to prevent product contamination.
  • Bspp or Npt threads, ASA or DIN flange connections
  • High flow rates with low pressure drops
Drybreak Hose UnitDrybreak Hose UnitDrybreak Hose Unit

Please contact our Sales Department for a quotation. We require the following information:-

  • Line size
  • Front flange diameter
  • Preferred body material
  • Preferred seal material
  • Preferred line side termination type
  • Medium, pressure, temperature and flow rate
  • Any other requirements or application details

 We have now increased our stocks of these parts so we can offer more on a next day despatch to the UK.


Product also Known As: Dry Disconnect Coupling
