Storz x Hosetail

Storz in Aluminium, fitted with Nitrile suction and delivery seals as standard. Storz are also available in Brass and Stainless Steel.




Storz Size Ka
in mm
To suit
Hose Size
Part Number
25-D 31 3/4" LS-25A
25-D 31 1" LS-25
38 51 1" LS-38A
38 51 1-1/4" LS-38
38 51 1-1/2" LS-38Z
52 66 1" LS-52A
52 66 1-1/4" LS-52B
52-C 66 1-1/2" LS-52
52-C 66 2" LS-52Z
65 81 2" LS-65A
65 81 2-1/2" LS-65
75-B 89 2" LS-75A
75-B 89 2-1/2" LS-75B
75-B 89 3" LS-75
100 115 4" LS-100Z
110-A 133 4" LS-100
125 148 5" LS-125
150 160 6" LS-150

Suitable for both suction and delivery applications, this 'Storz' hose tail can be clamped using our 'Band-Strap'product. Supplied with a white nitrile suction and delivery gasket as standard, the black nitrile, a Viton or an EPDM gasket are all available to order.

All 'Storz' are also available in Forged Aluminium, Brass and Stainless Steel.

The versatile 'Storz' coupling is widely used in the fire industry, where, in the UK, it is used for foam systems. A wide range of fire accessories are available with 'Storz' couplings as standard.

Road tankers involved in dry products, cement for example, are also a large UK market, along with the related loading and unloading facilities. The simple design, and hermaphrodite nature of the coupling ensure simplicity and security.

1-1/2", 1-1/4", short style delivery tails and smooth tails to DIN standard are also available to order.

The couplings are normally secured using a Spanner which is also available from stock.

Storz x Hosetail

Part No b (Ka)
in mm
D
in mm
d
in mm
L
in mm
Burst
Pressure
in Bar
Max Working
Pressure
in Bar
Weight
in Kgs
LS-25 31 25 19 55 35 16 0.5
LS-52 66 38 32 90 35 16 0.6
LS-52z 66 52.5 46 90 35 16 0.7
LS-75 89 75.5 66 125 35 16 1.30
LS-100 133 100 86 170 35 16 3.20

All 'Storz' couplings, regardless of material or type, which have the same Ka dimension are suitable for use with each other. This feature make the 'Storz' system ideal in applications where hoses or piping of different sizes need to be joined with the minimum of number of adaptors.



Product also Known As: DIN14301, DIN14321, DIN14322, DIN14323
